Double Din Uniersal (TS6219) CAR MP5 Player

Double Din Uniersal (TS6219) CAR MP5 Player

Uniersal Car Multimedia Player


We are a professional Car Multimedia Player Solution Providers.

We have nearly 200 models for Car multimedia Player / Car MP5 Player.

Because there are too many models and styles, it is only for display reference,

If you need more models, please call or email.



Product Details

Double Din Uniersal (TS6219) CAR MP5 Player


We are a professional Car Multimedia Player Solution Providers.

We have nearly 200 models for Car multimedia Player / Car MP5 Player.

Because there are too many models and styles, it is only for display reference,

If you need more models, please call or email.

UNIVERSAL (TS6219) CAR MP5,car media

UNIVERSAL (TS6219) CAR MP5,car media

Car multimedia, Car DVD navigation


1. 6.2 inch 16:9 800*480 digital high definition TFT LCD touch screen

 2. Built-in GPS navigation system

 3. Build-in Bluetooth for hand free (Coming Tel No. display function & Call out directly by touch screen)

 4. SD card slot, support mp3/mp4/Divx/WM etc

 5. Compatible with mp3/mp4/DVD/VCD/CD/CD-R/Divx/CD-RW etc

 6. With excellent mechanical anti-vibration and electronic shock protection

 7. Uniquely designed circuitry including standby function to increase battery durability

 8. Adjustable parameters can be memorized automatically, and resume back to the default value

 9. 3D interface make operation to easy

 10. Real time clock function

 11. One channel video input, two channel video output; two channel audio input, three channel audio output

 12. Dualzone function (lister radio/CD while using GPS)

 13. 30 preset radio stations

 14. Multi-function OSD menu

 15. Small light available on the button of the panel

 16. Fluorescent keys available for the remote control

 17. Rearview mirror available

 18. Original Canbus system for steering wheel control

 19. Built-in TV tuner

 20. English/Arabic/Russian//Hebrew/Turkish languages etc are available

 21. Built-in IPOD(optional)

 22. Built-in ISDB-T or DVB-T MPEG 2/MPEG4 (optional)

 23. Built-in RDS (optional)

 24. Built-in 3G internet (optional)



Specification


System parameters

Working voltage

DC 11V-14V

Working current

MAX 15A

Standby current

25 mA

Video system

automatic PAL/NTSC

GPS specification

Operation system

WINCE 6.0 CORE

Support map

Garmin, Tomtom, IGO, Route 66 etc

Processor

SiRFatlasV

EMS memory

128MB SDRAM

Storage device

128MB

Display output

CVBS+S-VIDEO output

Audio output

Stereo CD Quality

Main frequency

600MHz

Support audio type

MP3/PCM/WMA

Support video type

ASF/AVI/WMV/DIVX

Chipset

SIRF STAR 3

Frequency

1.575GHz

Channel number

20channels

Tracking sense degree

-159dbm

Position accuracy

10m, 2D RMS, WAAS enable

Velocity

0.1m/s

Data renewal rate

1Hz

Re-catching time

average 0.1s

Hot start time

average 1s

Warm start time

average 38s

Cold start time

average 42s

The biggest fixed height

18000m

The biggest velocity

515m/s

Power specification

DV 12V, current<500mA

Consumption

4.5W(12V/360mA), normal 3W(12V/250mA)

DVD parameters

Video output range

1+10.2Vp-p(75Ω)

Disc spec

diameter 12cm disc

Compatible disc

DVD/VCD/CD/MP3/WMA/JPEG/MPEG4

Amplifier parameters

Testing voltage

13.8V

Maximum power output

4×45W

Speaker impedance

8Ω (4-8Ω acceptable)

Audio parameters

Track imbalance degree

≤2dB

Segregation degree

≥45dB

Frequency response

20Hz-20KHz (±3dB)

Volume adjustment

Low 100Hz±7dB

Medium 1KHz±7dB

High 10KHz±7dB

Radio parameters

FM/AM frequency

FM: 87.5MHz-108MHZ

AM: 522KHz-1620KHz

Tune method

PLL frequency complex tune

Display method

TFT Graphical User Interface OSD

Storage quantity

FM radio: 18channels

AM radio: 12channels

Search method

automatic/manual
